Short Description
Extruded acrylic sheet uses high-quality molding plastic PMMA of famous enterprises at home and abroad as raw material and adopts extrusion method for large-scale production with advanced equipment. The product has extremely small tolerance and high cost performance.
Introduction
Extruded acrylic products have the following advantages:
It has a light transmittance of over 92%, good surface hardness and luster, high processing plasticity, and a wide variety of plates and rich colors.
It can meet the individual pursuit of different grades, and the thick plate can still maintain high transparency; it has good toughness and is not easy to be damaged; it is easy to repair and maintain; the thickness is uniform and the tolerance is small.
Extruded acrylic sheet can used light diffuser acrylic sheet, the PMMA diffuser has the optical characteristics of plastic sheets such as high haze, high light transmittance, high diffusivity, etc., which can effectively transform point or line light sources into soft and uniform surface light sources, under the premise of achieving good light transmittance , At the same time, it has a good light source lattice shielding property. It is an ideal optical material to solve the secondary light distribution of LED lighting products, and it is the best light diffusion material for LED lighting products
Advantage of Extruded Acrylic Sheet
1)High impact resistance ability with lighter weight than glass.
2) Excellent electrical insulation, easy to fabricate, shape and clean.
3) High transparency & gloss, with light transmittance 93%. for clear sheet.
4) Strong surface hardness with good weather resisting property & ageing resistance.
5) 100% virgin raw material, no color fade within 8-10 years even for outdoor use.
6) Accurate measurement with lower thickness tolerance.
Specification
Product | Extruded Acrylic Sheet |
Density | 1.2g/cm3 |
Thickness | 0.8-12mm |
Size | 1220*2440mm 2000*3000mm ;Width: 600mm-2100mm ,length:600mm-6000mm |
Color | Transparent,white,red,black,yellow ,60 kind of colors |
Material | 100% virgin Mitsubishi raw material |
Technology | extruded acrylic sheet production process |
Quality | Our extruded crylic sheets conform to CE/SGS certificastes |
payment | L/C, T/T, Western Union, MoneyGram, Paypal |
MOQ | 100PCS |
Delivery | 10-15days after confirm your order |
Technical Data
Specific Gravity | 1.19-1.20 |
Rockwell Hardness | M-100 |
Shear Strength | 630Kg/cm2 |
Tensile Strength | 760Kg/cm2 |
Yield Strength | 1260Kg/cm2 |
Rupture Strength | 1050Kg/cm2 |
Light Transmittance | 94% |
Refractive Index | 1.49 |
Heat Distortion Temperature | 100℃ |
Thermal Forming Temperature | 140℃-180℃ |
Coefficient of linear Thermal Expansion | 6×10-5cm/cm/℃ |
Dielectric Strength | 20Kv/mm |
Water(24HRS)Absorption | 0.30% |
Application of Extruded Acrylic Sheet
1. Architectural application: show window, soundproof doors and Windows, daylighting cover, telephone booth, etc.
2. Advertising application: light box, signboard, exhibition rack, etc.
3. Transportation application: doors or windows on train, car, etc.
4. Medical application: infant incubator, all kinds of surgical medical instruments and civilian supplies: sanitary facilities,arts and crafts, cosmetics, brackets, aquatic animals, etc.
5. Industrial application: instrument surface plate and cover, etc.
6. Lighting application: fluorescent lamp, chandelier, street lamp shade, etc
