Short Description
PETG sheet of type: transparent PETG sheet ,PETG clear sheet ,glossy white PETG sheet ,matt white PETG sheet ,gloosy black PETG sheet,matt black PETG sheet, Semi transparent PETG sheet,PETG colored sheet.
Introduction
PETG (Polyethylene terephthalate glycol), thermoplastic polyester that provides excellent toughness, chemical resistance and is easy to thermoform. With its low forming temperature, PETG can be readily vacuumed and pressure-formed as well as heat bent. PETG fabricates well using processes like die cutting, drilling, routing, and bending. PETG is a high impact, co-polyester material, but it does not hold up well in outdoor applications. Because of its soft surface it is also vulnerable to scratching in high contact environments.
PETG sheet is a thermoplastic sheet made by Polyethylene terephthalate resin.PETG offers the capability to produce complex shapes, precise details, deep draws and compound curves without worrying about durability. PETG is easily formed, die-cut and punched. It also brings increased design freedom and lower fabrication costs. In sheet form, PETG has the impact strength and fabrication ease that acrylic can`t touch, with the durability to significantly reduce packaging and shipping costs.
Advantage of PETG Sheet
•Outstanding thermoforming characteristics, particularly in deep draw applications
•Good impact resistance
•Less brittle than acrylic
•Resistant to common cleaners used on point of purchase displays
•Allows for rigid thermoforming cycle times
•FDA compliant grades available
•Impact strength greater than acrylic and approaches polycarbonate
•86% light transparency compared to 87% for polycarbonate and 92% for acrylic
•Die cuts/punches easily
•Low forming temperature
•Printable
•Chemical resistant
•Self-extinguishing
Specification
Product | PETG Sheet |
Density | 1.27g/cm3-1.34g/cm3 |
Thickness | 0.2mm-6mm |
Size | 610*610mm,700*1000mm,915*1220mm,915*1830mm,1220*2440mm, Customized |
Color | clear, transparent,glossy white,matt white,forsted white,black red,green,blue,yellow etc. |
payment | L/C, T/T, Western Union, MoneyGram, Paypal |
MOQ | 200PCS or 1Tons |
Delivery | 10-15days after confirm your order |
Technical Data
Intrinsic Viscosity(dL/g) | 0.750+/-0.015 |
Specific Gravity(kg/cm³) | 1.27 |
Moisture Absorption(%) | 0.15 |
Tensile Strength@Yield 50mm/min( inch/min)(kgf/cm²) | 496 |
Tensile Strength@Break 50mm/min( inch/min)(kgf/cm²) | 281 |
Elongation@Yield 50mm/min( 2inch/min)(%) | 3.7 |
Elongation@Break 50mm/min(2 inch/min)(%) | 136 |
Flexural Strength 1.27mm/min(2 inch/min)(kgf/cm²) | 620 |
Flexural Strength 1.27mm/min(3 inch/min)(kgf/cm²) | 20800 |
Low temperature falling dart impact(g) | 791 |
Atmospheric temperature falling dart(g) | 1701 |
Lzod Impact Strength Notched@23 ℃(J/m) | 98 |
Rockwell Hardness(℃) | 106 |
Heat Distortion Temperature 0.45Mpa(66 psi)(℃) | 77 |
Application of PETG Sheet
PETG is used as a Midrange priced product between Acrylic and Polycarbonate. The clearity of PETG approchies that of Acrylic and Impact Resistance of Polycarbonate. Also is used in Signing, Glazing, POP Displays, etc.
•Signs
•Sign and graphic holders
•Point of purchase displays
•Merchandisers
•Table top displays
•Table tents
•Product displays
•Trays
