PVC Co-Extrusion Foam Board

PVC co-extruded foam board uses pvc as inner foam, the outside is also pvc veneer, so the density and hardness is larger and higher than plate made with other materials. The smooth surface of the expanded PVC sheet can be used for screen printing, painting, cut mounting, gluing, engraving, lapping.

  • GK-PFB

  • GoKai

Availability:
Quantity:
Inquire Add to Basket

Short Description

PVC co-extruded foam board uses pvc as inner foam, the outside is also pvc veneer, so the density and hardness is larger and higher than plate made with other materials. The smooth surface of the expanded PVC sheet can be used for screen printing, painting, cut mounting, gluing, engraving, lapping.



Introduction

White PVC co-extruded  foam board is using the co-extrusion production pocess,which forms a sandwish board structure-the core is celluar pvc and the both outer skin is rigid pvc. It a lightweight,expanded rigid PVC foam board that is used for a variety of applications including signs and display, exhibit booths, photo mounting ,interior design, thermoforming, prototypes,model making. Comparing with PVC celuka foam board, PVC co-extruded foam has more smoother and shiny surface. Surface harness is much better than celuka , which will benefit for using in some application,such as table top, interior decoration for boats,ship ,vehicle,train.



Advantage of PVC Co-Extruded Foam Board

1.  Light-weight,  easy storage and processing,  smooth and rigid surfaces

2.  Sound & heat insulation , noise absorption, not easy to scratch

3.  waterproof, Antiflaming and self-extinguishing，Moisture-resistant

4.  Easy fabrication with conventional tools, such as blades, saws, hammers and drills.

5.  Flat surface applicable to screen printing, painting, mounting.

    Bonding together with other PVC products by PVC adhesives

6.  Suitable for thermal shaping, thermal bending and fold processing.



Technical Data

Model Number

GK-PFB

Size

1220x2440mm

Density

0.5g/cm3—0.9g/cm3

Thickness

1-20mm

Tolerances

1) ±5mm on width. 2) ±10mm on length.

Color

White

Water Absorption %

0.19

Tensile strength at Yield Mpa

19

Elogation at break %

> 15

Flexual Modulus Mpa

> 800

Vicat Softening point °C

≥70

Dimensional stability%

±2.0

Screw holding strength N

> 800

Choppy Impact Strength KJ/m2

> 10



Application of PVC Co-Extruded Foam Board

1. Wall and ceiling cladding

2. Partitions

3. Shop outfitting

4. Point of sale

5. Signage

6. Fabricated displays

7. Exhibition stands

8. Cabinetry

9. Fenestration

10. Marine industry

11. Medical screens

12. Food preparation areas
